If you thrive on connection to the trail, if you live for the flow of a screaming descent—Komodo will take you there without the added weight and complexity of dual suspension.
Geometry
Sizing
If you thrive on connection to the trail, if you live for the flow of a screaming descent—Komodo will take you there without the added weight and complexity of dual suspension.
Geometry
Sizing
| Color | Blue Vapor, Rhino |
|---|---|
| Rear Derailleur | Shimano Deore, 12-speed |
| Saddle | WTB Volt |
| Pedals | Sold separately |
| Brakes | Shimano MT420 4-piston hydraulic disc, 180mm RT30 rotors |
| Stem | Race Face Ride, 50mm |
| Tape/Grips | Jamis Lock-On |
| Handlebars | Race Face Ride, 35 x 760mm |
| Shifters | Shimano Deore, 1×12-speed |
| Cassette/Rear Cogs | Shimano M6100, 12-speed, 10-51T |
| Chain | KMC X12, 12-speed |
| Size | 15-inch, 17-inch, 19-inch, 21-inch |
| Bottom Bracket | Race Face BSA |
| Crankset | Race Face Ride, 32T |
| Tires | WTB Vigilante 29 x 2.5" Front & Trail Boss 29 x 2.4" Rear, TCS Tubeless |
| Rims/Wheels | Stan's No Tubes Flow D 29" rims, Shimano MT410 hubs, stainless spokes |
| Axles | Front: 110 x 15mm thru-axleRear: 148 x 12mm thru-axle |
| Headset | FSA Orbit 1.5 Zero-Stack internal cup, 8mm cone spacer |
| Fork | Rock Shox 35 Silver TK 29", Solo Air compression, Turn Key lockout, external rebound, 35mm steel stanchions, magnesium lowers, 140mm travel |
| Frame | Triple-butted 6061 aluminum, 1.5 – 1 1/8" tapered head tube, post mount disc brakes, internal dropper post routing, replaceable derailleur hanger |
| Seat Post | KS Rage Dropper, Southpaw remote |
